Anritsu-BTS Master (Model:MT8221B)

0
225
Vui lòng liên hệ với chúng tôi– chúng tôi sẽ liên hệ lại với khách hàng bằng điện thoại hoặc email.
Lưu ý: Tham khảo ý kiến của nhân viên INO sẽ giúp bạn tiết kiệm được thời gian và chi phí khi cần mua sắm. ​​Với sự tư vấn của chúng tôi, bạn sẽ không gặp khó khăn khi tìm hiểu về đặc tính của sản phẩm cần mua.

Features

  • 2-port Cable and Antenna Analyzer 400 MHz to 4 GHz
  • Bias Tee
  • GPS Receiver
  • Spectrum Analyzer 150 kHz to 7.1 GHz
  • Power Meter 10 MHz to 7.1 GHz
  • High Accuracy Power Meter (up to 26 GHz with external sensor)
  • Interference Analyzer 100 kHz to 7.1 GHz
  • Channel Scanner 100 kHz to 7.1 GHz
  • Vector Signal Generator 400 MHz to 6 GHz
  • Signal Quality Analyzers
  • GSM/EDGE, W-CDMA/HSPA+, LTE, TD-SCDMA/HSDPA
  • CDMA, EV-DO, Fixed WiMAX, Mobile WiMAX
  • Backhaul Quality Analyzers
  • T1, T3
  • E1

The BTS Master MT8221B is Anritsu's high performance base station analyzer. From the ground up it has been designed to support 4G standards and installed 2G/3G networks. The MT8221B's platform provides a 20 MHz demodulation capability to support LTE bandwidths from 1.4 to 20 MHz. It also features a 30 MHz Zero-Span IF Output for external demodulation of virtually any other wideband signal. In addition, a Vector Signal Generator option is available for comprehensive receiver testing capability with the flexibility to generate two modulated signals plus noise.

The BTS Master MT8221B Base Station Analyzer is ideal for senior cell site technicians and RF engineers to accurately and quickly test and verify the installation and the commissioning of base stations and cell sites for optimal wireless network performance and for the on-going maintenance and troubleshooting to keep your wireless network infrastructure fine-tuned.

When it comes to meeting your key performance indicators (KPIs) such as dropped calls, call denial, or call blocking rates due to a malfunction at the cell site or interference, the BTS Master MT8221B is the all-in-one instrument that you can count on for quick problem resolution.

The Signal Analyzers for 2G/3G and approaching 4G networks can test the RF Quality and the Modulation Quality of a wireless signal to verify the performance of virtually every subsystem in a base station's transmitter. With the Downlink Over-the-Air (OTA) Quality tests you can verify the performance of the downlink with the OTA scanners.

The BTS Master MT8221B is small, lightweight, and battery operated making it easy for the technician to use it anywhere at a cell site. With less than 5 minute warm-up time you get more useful battery life and you can start making measurements faster. Through Anritsu's field-proven design know-how and 50 hours of production burn-in and temperature cycling on every unit you can count on your MT8221B to give you years of reliable performance in the rugged outdoor environment.

Whether line sweeping is required or analysis of its associated components and antennas, the need to quickly troubleshoot down to a field replaceable unit (FRU) in the base station, to verify the performance of the cell site's backhaul lines, or to hunt down your toughest interference problems; the BTS Master MT8221B is the ideal all-in-one instrument.

Cable and Antenna Analyzer Measurements

  • VSWR, Return Loss, Cable Loss, Distance-to-Fault (DTF) Return Loss, DTF VSWR, 1/2-port Phase, 2-port Gain, Smith Chart

Spectrum Analyzer Measurements

  • Field Strength, Occupied Bandwidth, Channel Power, ACPR, AM/FM/SSB Demodulation, C/I, Gated Sweep

Interference Analyzer Measurements

  • Spectrogram, Signal Strength Meter, Received Signal Strength Indicator (RSSI)

Channel Scanner Capability

  • Scan 20 channels at once by frequency or channel number, up to 1200 channels, auto-save with GPS tagging

Vector Signal Generator Capability

  • Generate up to 2 modulated tones, up to 10 MHz bandwidth plus noise
  • Check BTS receiver's sensitivity, adjacent channel selectivity, blocking, intermodulation rejection

Signal Quality Analyzers Measurements

  • RF Quality Measurements, Modulation Quality Measurements, Over-the-Air Quality Measurements

Backhaul Quality Analyzer Measurements

  • Electrical Testing – Error Detection, Error Analysis, Rx Signal, VF

 Option

Description
 MT8221B-010  High Voltage Variable Bias Tee
 MT8221B-0031  GPS Built-in Receiver (Requires Antenna P/N 2000-1528-R, sold separately)
 MT8221B-0019  High Accuracy Power Meter (Requires USB Power Sensor)
   MT8221B-0025  Interference Analyzer
 MT8221B-0027  Channel Scanner
 MT8221B-0089  Zero-Span IF Output (30 MHz IF Bandwidth)
 MT8221B-0090  Gated Sweep
 MT8221B-0023  Vector Signal Generator
 MT8221B-0040  GSM/GPRS/EDGE RF Measurements
 MT8221B-0041  GSM/GPRS/EDGE Demodulation
 MT8221B-0044  W-CDMA/HSDPA RF Measurements
 MT8221B-0045  W-CDMA Demodulation
 MT8221B-0065   W-CDMA/HSDPA Demodulation
 MT8221B-0035  W-CDMA/HSDPA Over-the-Air (OTA) Measurements
 MT8221B-0060  TD-SCDMA/HSDPA RF Measurements
 MT8221B-0061  TD-SCDMA/HSDPA Demodulation
 MT8221B-0038  TD-SCDMA/HSDPA Over-the-Air (OTA) Measurements
 MT8221B-0541  LTE RF Measurements
 MT8221B-0542  LTE Modulation Measurements
 MT8221B-0546  LTE Over-the-Air (OTA) Measurements
 MT8221B-0543 LTE BW = 15 MHz, 20 MHz (requires option 0541, 0542, 0551 or 0552)
 MT8221B-0551  TD-LTE RF Measurements (BW = 10 MHz)
 MT8221B-0552  TD-LTE Modulation Measurements (BW = 10 MHz)
 MT8221B-0556  TD-LTE Over-the-Air Measurements
 MT8221B-0042   cdmaOne / CDMA2000 1X RF Measurements
 MT8221B-0043  cdmaOne / CDMA2000 1X Demodulation
 MT8221B-0033  cdmaOne / CDMA2000 1X Over-the-Air (OTA) Measurements
 MT8221B-0062  CDMA2000 1xEV-DO RF Measurements
 MT8221B-0063  CDMA2000 1xEV-DO Demodulation
 MT8221B-0034  CDMA2000 1xEV-DO Over-the-Air (OTA) Measurements
 MT8221B-046  Fixed WiMAX RF Measurements
 MT8221B-047  Fixed WiMAX Demodulation
 MT8221B-0066  Mobile WiMAX RF Measurements
 MT8221B-0067  Mobile WiMAX Demodulation
 MT8221B-0037   Mobile WiMAX Over-the-Air (OTA) Measurements
 MT8221B-0051  T1 Analyzer
 MT8221B-0052  E1 Analyzer
 MT8221B-0053  T3/T1 Analyzer

 MT8221B-0098  Standard Calibration
 MT8221B-0099  Premium Calibration

* Options 51 – T1 Analyzer, 52 – E1 Analyzer and 53 – T3/T1 Analyzer are mutually exclusive.
