Rohde-schwarz- Power Meter (Model:R&S®NRP2)

0
393
Vui lòng liên hệ với chúng tôi– chúng tôi sẽ liên hệ lại với khách hàng bằng điện thoại hoặc email.
Lưu ý: Tham khảo ý kiến của nhân viên INO sẽ giúp bạn tiết kiệm được thời gian và chi phí khi cần mua sắm. ​​Với sự tư vấn của chúng tôi, bạn sẽ không gặp khó khăn khi tìm hiểu về đặc tính của sản phẩm cần mua.

Key Facts

  • Supports all sensor-dependent measurement functions
  • Expandable to up to four measurement channels
  • Straightforward numerical and graphical display
  • Brilliant TFT color display
  • Optionally integrated 50 MHz/1 mW reference source
  • Hardware interfaces for remote control and triggering
  • Emulation of other legacy power meter
  • User-programmable save/recall locations

Brief Description

The compact, robust R&S®NRP2 base unit with color display supports up to four R&S®NRP-Zxx power sensors and all sensor-dependent measurement functions. Measured values are displayed numerically or graphically, depending on the measurement function. The window-based user interface allows simple, intuitive operation; the base unit can be remotely controlled via Ethernet, GPIB or USB.

Specifications

  • Level range: -67 dBm to +45 dBm (sensor dependent)
  • Frequency range: DC to 110 GHz (sensor dependent)
  • Measurement speed: 1500 measurements per second in the buffered mode
  • Linearity uncertainty: 1.5 % (20 to 25 °C, f = 100 MHz to 4 GHz)

Resource & Download

Lưu ý: Nếu một thiết bị nào đó không được liệt kê ở đây, điều đó không có nghĩa rằng chúng tôi không hỗ trợ được bạn về thiết bị đó. Hãy liên hệ với chúng tôi để biết danh sách đầy đủ về thiết bị mà chúng tôi có thể hỗ trợ và cung cấp.
INO: Bán, Báo giá, tư vấn mua sắm và cung cấp, tư vấn sản phẩm thay thế; tương đương, hướng dẫn sử dụng, giá…VNĐ, …USD info@ino.com.vn | Tel: (+84) 028 73000184 | Rohde-schwarz- Power Meter (Model:R&S®NRP2).
