New Gas Detection Rack Mount Control System

The NEW Digital Modbus Rack Mount Controller TA2048MB designed and manufactured by MILRAM TECHNOLOGY (USA), features a 48channel system with 3 separate 16 channel Modbus Networks. Local or remote power supply options. Multidrop smarter Transmitter (sensor) Networks, which eliminates separate costly wiring to each Transmitter. RS485 digital Modbus RTU; half or fullduplex configuration. Four relays (SPST), 10 Amp. common to all channels on each Network. Select energized/nonenergized, latching/nonlatching function. Low, Mid, High and Fault relays. LED alarm indicators. Audible buzzer alarm. Backlit 16 characters x 2 lines LCD display. Autoscrolls to provide channel data and fault conditions. Simple front panel, push button channel setup. Redundant storage of configuration parameters for highest reliability. Rack mount or wall mount enclosures. Explosion proof available. Continuous Diagnostics. Optional: Remote Relay Modules, Remote Analog Output Module, and Remote Digital Output Module, Modbus enabled, can be installed at any point on RS485 network to minimize wiring. Use with any MilRam smarter Transmitter Toxic/LEL/VOC/ Oxygen: hundreds of different gases and vapors
