Water quality monitoring of Biomonitoring System – HATOX-2000

0
526

Microbial Fuel Cell (MFC)-type Biomonitoring System, HATOX-2000, is toxic substance detecting equipment that uses MFC, which is the first source technology in the world. HATOX-2000 is a toxin detector that features fast response and high sensitivity to toxic substances. It is equipped with an eco-friendly system that reacts to diverse toxic substances yet doesn’t emit any hazardous chemicals. It is not only easy to maintain, but also has the advantage of cost efficiency. It also has less clogging due to the use of a large drain.

Characteristics

HATOX-2000

MFC type sensor

Fast response and high sensitivity to toxins

Stable system free of false alarm

Easy maintenance

Economical maintenance expenses

Status condition display

Principle

HATOX-2000 detects level of toxicity by using MFC. When a sample containing toxic substance enters, the value of the current changes as the toxic substance affects the normal electron transport system of the microbe. Here, the difference in the value of current is displayed as level of toxicity.

Specification

    • Measurement item

Toxicity (TOX)

    • Measurement method

Microbial fuel cell (MFC) using electrochemically active bacteria(EAB)

    • Measurement principle

Conversion of change of electrical signal generated by bacteria in MFC to toxicity

    • Measurement range

-100~+100%

    • Measurement interval

10 minutes (Adjustable)

    • Response time

Within 30 minutes

    • Operation system

Windows 7 (CPU process) or more

    • Output

TCP/IP, DC 4~20mA, RS-232C

    • Status display

Normal operation, on calibration, error

    • Display

Color LCD 10.4″ (Touch screen)

    • Power

AC 220V, 50/60Hz

    • Power consumption

Average 150W (Maximum 250W)

    • Data storage capacity

HDD 100G or more

    • Data output

USB terminal

    • Enclosure/ Size

Steel, IP55 / 600(W) — 662(D) — 1700(H) mm

    • Automatic thermostat

Thermoelectric element type

    • Operating humidity

RH 95% or less

Application

Application Field

Surface water monitoring

    • River, lake, river water quality
    • Waterworks facilities (intake station and Water plant, etc.)

Water quality TMS

    • Sewage treatment plant, Wastewater treatment plant
    • Wastewater discharging facility, Rural sewage treatment facility, etc.

Process control, etc.

    • STP process management,
    • IWWTP process management, etc.
