SmartLine SafetyModul ( AC009S )

0
328
Vui lòng liên hệ với chúng tôi– chúng tôi sẽ liên hệ lại với khách hàng bằng điện thoại hoặc email.
Lưu ý: Tham khảo ý kiến của nhân viên INO sẽ giúp bạn tiết kiệm được thời gian và chi phí khi cần mua sắm. ​​Với sự tư vấn của chúng tôi, bạn sẽ không gặp khó khăn khi tìm hiểu về đặc tính của sản phẩm cần mua.

 Product characteristics

Safe active AS-i module

Mounting on DIN rail

Combicon connection

Performance Level e
to EN ISO 13849-1 et IEC 61508 / SIL 3
for the connection of mechanical contacts

Complies with the requirements:
EN ISO 13849-1: Category 4 PL e
IEC 61508: SIL 3

 Electrical data

Electrical design



2 safe inputs / 2 non-safe LED outputs / 2 non-safe relay outputs

Operating voltage [V]



26.5…31.6 DC

Current consumption [mA]



< 250

Max. current load per module [mA]



6000

Input current [mA]



10

 Inputs

digital

Circuit



DC PNP

Sensor supply



AS-i

Cross-bridging detection



ja

Short-circuit detection



ja

 Outputs

Relay outputs



2

Voltage range [V]



10…240 AC / 24 DC

Actuator supply



24 V DC

Electrically separated



yes

Integrated watchdog



yes

Short-circuit proof



no

LED output



Supply from AS-i

 Environment

Ambient temperature [°C]



-25…50

Storage temperature [°C]



≤ 80

Max. relative air humidity [%]



< 80, Condensation not permissible

Protection



IP 20

 Tests / approvals

EMC



EN 50295

 Safety classification

MIssion time TM [h]



175200, (20 years)

Safety-related reliability PFHd [1/h]



4E-09

MTTFd [Years]



8513

DC/CCF/Cat.



99 % / 65 % / 4

 AS-i classification

AS-i version



2.11 / 3.0

Extended addressing mode possible



no

AS-i profile



S-7.B.E

I/O configuration [hex]



7

ID code [Hex]



B.E

AS-i certificate



62001

Max. number of safety modules per master



31

 Mechanical data

Cable length between module and mechanical contacts



< 10 m

Housing materials



PA

Weight [kg]



0.2

 Displays / operating elements

Power LED



green

Error LED



red

Function display LED



yellow

 Electrical connection

Connection



Combicon

 Accessories

Accessories (optional)



Combicon connector
